NV200
Military NVIDIA Jetson Orin NX IP65 Computer
- Military Jetson Orin NX 16G LPDDR5 DRAM
- Data Input : 4x3G-SDI, 2xLAN , 4xGMSL
- Connectivity : 4G/5G LTE, WiFI, CAN BUS, RS232/422/485
- MIL-STD-810 Vibration Method 514.6 : ◎Acceleration : 5.0 Grms
- MIL-STD-810 Shock Method 516.6 : ◎Acceleration: 40G
- MIL-STD-461 Ground Vehicle EMI Filter
- IP65 Sealed with DTL38999 Connector
- Extended Temperature -20~+60 Degree
- Technical Profile
- Specifications
- Order Information
- Download
Technical Profile
- Introduction
-
NV200 is an ultra-small-form-factor (USFF) MIL-SPEC rugged edge compute solution. Designed using a Modular Open Systems Approach (MOSA) with a modular chassis and architecture design, integrating either the NVIDIA Jetson Orin NX edge AI system on module (SOM), NV200 provides the performance and flexibility demanded by emerging autonomous and uncrewed missions, in an ultra-compact and lightweight form factor. NV200 is engineered to withstand austere environments and is SWaP-optimized for integration and deployment in highly space-constrained platforms.
NVIDIA® Jetson Orin™ NX
Equipped with an NVIDIA Ampere architecture GPU featuring 1024 CUDA® and 32 Tensor Cores, the NV200, integrated with the NVIDIA Jetson Orin™ NX module, delivers up to 100 TOPS of AI performance in the smallest Jetson form factor, with power configurable between 10W and 25W. This provides up to 3X the performance of Jetson AGX Xavier and up to 5X the performance of Jetson Xavier NX. Bring your next-gen products to life with the world’s most powerful AI computers for energy-efficient autonomous machines. Besides, NVIDIA® Jetson Orin™ modules have 8X the performance of the last generation for multiple concurrent AI inference pipelines, plus high-speed interface support for multiple sensors, making them the ideal solution for a new age of robotics..
- AI-driven Tracking for Anti-drone System
-
The growing presence of commercial and military drones poses a significant threat to critical infrastructure, military installations, and restricted areas. NV200 GPU computer, capable of running advanced AI algorithms such as Convolutional Neural Networks (CNNs) and object tracking models, processes incoming data to classify potential drone threats, track their movement in real time, determine precise coordinates, and predict their trajectory. This system can integrate with a Command & Control center, transmitting real-time data to support threat assessment and fire control decision-making.
NVIDIA® JetPack™ Support
Compatible with NVIDIA JetPack™ 5.0 and higher, the NV200 enables users to harness a comprehensive library of tools for building top-tier inference models. This enhances application performance by accelerating graphics, data processing, and image classification functions which can be tailored to your specific needs.
 |
 |
 |
 |
Edge AI Platform |
SFF & SWaP |
Open Modular Architecture |
MIL-STD 810 Rugged |
| Can integrate the NVIDIA Jetson Orin NX (8GB or 16GB), delivering up to 100 TOPS of AI performance for next-gen autonomous and uncrewed mission-critical applications. | Ultra-compact and lightweight, SWaP-optimized for integration and deployment in highly space-constrained vehicles. | Orin NX and SMARC x86-based architecture/processor options. Robust IO and configuration options, including multiple USB 3.0, GbE, serial, display, video capture, GPS, GPIO. | Engineered for austere environments. -40C to +55C operating temp, passive cooled. Fully sealed. MIL-STD-810H, MIL-STD-461G, MIL-STD-1275E/704F. |
Specifications
| System | |
|---|---|
|
High performance Processor |
Jetson Orin NX 16GB : 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU Jetson Orin NX 8GB : 6-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU |
| GPU | 1024-core NVIDIA Ampere GPU with 32 Tensor Cores (Max. Frequency: 918MHz |
| AI Performance |
Jetson Orin NX 16GB: Up to 100 (Sparse) INT8 TOPs and 50 (Dense) INT8 TOPs Jetson Orin NX 8GB: Up to 70 (Sparse) INT8 TOPs and 35 (Dense) INT8 TOPs |
| Memory Type |
Jetson Orin NX 16GB: 16GB 128-bit LPDDR5 DRAM Jetson Orin NX 8GB: 8GB 128-bit LPDDR5 DRAM |
| Expansion Slot | |
| Expansion Slot |
1x WiFi Module (M.2 2230 E-KEY) 1x M.2 2230 M key , 1x M.2 2280 M Key Optional GMSL2 module with 4x FAKRA connector |
| Display | |
| Graphics Interfaces | 1x HDMI 2.0 (max resolution 3840x2160) |
| Storage | |
| M.2 |
1x M.2 2230 Key-M slot (PCIex1) 1x M.2 2280 Key-M (NVMe) slot ( Option) |
| Ethernet | |
| Controller | 2x GLAN |
| Front I/O | |
| Ground Screw | 1x |
| DC-IN | 18V~32V |
| X1 | 2x 1GbE LAN |
| X2 | 1x CAN + 1x RS232/422/485 + 4x DIO |
| X3 | 1x HDMI |
| Rear I/O (Option) | |
| Antenna (Option) |
2x Antenna holes for Wi-Fi 5/6 modules (PR-SMA ant.) 2x Antenna holes for LTE/5G module (SMA ant.) 1x Antenna hole for GNSS (RP-SMA ant.) |
| GMSL2 | 2x2 Mini FAKRA SMB Plug Z-code, 4x GMSL(2) connectors |
| 3G-SDI (Option) | 4x BNC connectors |
| Access panel | |
| 1x Boot LED | |
| 2x USB3.1 Type-C | |
| 1x USB3.1 Type-C for Recovery | |
| 1x Recovery Button | |
| 1x Reset Button | |
| Power Requirement | |
| Power Input | DC-IN 18V to 32V |
| Operating System | |
| Operating System | Ubuntu 20.04 with JetPack6.0 |
| Physical | |
| Dimension (WxDxH) | 220 x 300 x 88 mm |
| Weight | 3 Kg |
| Chassis | Aluminum AL6061 |
| Heatsink | Aluminum Alloy, Corrosion Resistant. |
| Finish | Anodic aluminum oxide (Color). |
| Cooling | Natural Passive Convection/Conduction. No Moving Parts |
| Ingress Protection | IP65 |
| Environmental | |
| MIL-STD-461 (Options) | |
| EMC |
CE102 basic curve, 10kHz - 30 MHz RE102-4, (1.5 MHz) -30 MHz - 5 GHz RS103, 1.5 MHz - 5 GHz, 50 V/m equal for all frequencies |
| Reliability |
No Moving Parts; Passive Cooling. Designed & Manufactured using ISO 9001/2000 Certified Quality Program. |
| Operating Temp. | -20 to 50°C (ambient with air flow) |
| Storage Temp. | -40 to 85°C |
| Relative Humidity | 5% to 95%, non-condensing. |
Order Information
Download
| Attachment | Size |
|---|---|
| NV200-2LGS16 Outgoing Quality Inspection Report.pdf (11.91 MB) | 11.91 MB |
| NV200-2LGS16 Performance Test Report.pdf (13.45 MB) | 13.45 MB |
